Product Description:
1.Germanic technology
Adopting Germany Rotorcomp technology a compact original screw machine and the related pieces
2.Reliability and durable
Rotator has unique appearance curve, and even turn more smoothly
Let rotator wear to a minimum, solid underframe and the crankcase, all of them have been assigned to deal with the surface tension automatically adjust and just performance V-belt drive
Sealed efficient electrical crankcase, IP54 protection, insulation Class F
Balancing the rotational components that suitable to the smooth and continuous operation
3.Easy protection
External oil separator filter replacement easier
Control components more easily
The doors are easy to open, more space for maintenance
Automatic control and safety monitoring
4.Easy installations
Compact machinery not hold too much space
With shock mounts, the installation does not require specific strength on the ground
Equipped with heavy boxes to facilitate the protection of power line easy link power
5.Excellent performances
Strong cooling fan improve compressor inlet pressure and increase export flows
Output the highest pressure to 15bar
Low compressing air temperature
Sophisticated filter separator most Export Oil isolation, low content to 2-4ppm
| Model |
Capacity(m3/min) |
Motor(KW) |
Noise LeveldB(A) |
L*W*H(mm) |
Weight(kg) |
| 0.7MPa |
1.0MPa |
1.25MPa |
| LG15 |
1.76 |
1.50 |
1.16 |
11.0 |
65 |
660*980*995 |
330 |
| LG20 |
2.24 |
1.96 |
1.51 |
15.0 |
68 |
660*980*995 |
340 |
| LG25 |
2.91 |
2.62 |
2.20 |
18.5 |
68 |
660*980*995 |
362 |
| LG30 |
3.46 |
3.10 |
2.66 |
22.0 |
70 |
790*1210*1220 |
445 |
| LG40 |
4.38 |
4.01 |
3.52 |
30.0 |
70 |
790*1210*1220 |
490 |
| LG50 |
6.15 |
5.24 |
4.56 |
37.0 |
72 |
1100*1500*1580 |
750 |
| LG60 |
7.25 |
6.51 |
5.55 |
45.0 |
72 |
1100*1500*1580 |
850 |
| LG75 |
9.30 |
7.96 |
6.70 |
55.0 |
75 |
1100*1500*1580 |
950 | |
